Technical Specifications |
| |
|
|
|
| |
|
| Specifications -28025 |
| Size |
80 X 80 X 25 mm |
| Motor |
Single Phase, Shaded Pole.Impendence Protection |
| Frame ( Housing ) |
Aluminium Diecast , Painted Black |
| Impellor |
Thermoplastic, Non-flamble. UL94V0 Rating |
| Inslulation Resistance |
Min 10 Megohms @ 500 VDC |
| Dielectric Strength |
1000 VAC for one minute |
| Operating Temperature |
Ball Bearing :- 20 ~ + 80 *
Sleeve Bearing : - -10 ~ 56 * C. |
| Net Weight |
245 grms |
|
| |
|
|
|
| |
|
|
|
| |
|
 |
 |
| |
|
|
| |
|
Technical Specifications |
| |
|
|
| Specifications -22038 |
| Size |
120 X 120 X 38 mm |
| Motor |
Single Phase, Shaded Pole.Impendence Protection |
| Frame ( Housing ) |
Aluminium Diecast , Painted Black |
| Impellor |
Thermoplastic, Non-flamble. UL94V0 Rating |
| Inslulation Resistance |
Min 10 Megohms @ 500 VDC |
| Dielectric Strength |
1500 VAC for one minute |
| Operating Temperature |
Ball Bearing :- 20 ~ + 80 *
Sleeve Bearing : - -10 ~ 56 * C. |
| Net Weight |
536 grms |
|
| |
|
|
|
| |
|
| Cooling Fans - REC-22038 [Super High Speed] |
|
| |
|
 |
 |
| |
|
|
|
|
| |
|
Technical Specifications |
| |
|
|
|
|
| |
|
| Specifications -22038 Super High Speed |
| Size |
120 X 120 X 38 mm |
| Motor |
Single Phase, Shaded Pole.Impendence Protection |
| Frame ( Housing ) |
Aluminium Diecast , Painted Black |
| Impellor |
Thermoplastic, Non-flamble. UL94V0 Rating |
| Inslulation Resistance |
Min 10 Megohms @ 500 VDC |
| Dielectric Strength |
1500 VAC for one minute |
| Operating Temperature |
Ball Bearing :- 20 ~ + 80 *
Sleeve Bearing : - -10 ~ 56 * C. |
| Net Weight |
530 grms |
|
| |
|
|
|
| |
|
| Cooling Fans - REC-22038 [Alarm Type] |
|
| |
|
 |
 |
| |
|
|
| |
|
Technical Specifications |
| |
|
|
|
| |
|
| Specifications -22038 Alarm Type |
| Size |
120 X 120 X 38 mm |
| Motor |
Single Phase, Shaded Pole.Impendence Protection |
| Frame ( Housing ) |
Aluminium Diecast , Painted Black |
| Impellor |
Thermoplastic, Non-flamble. UL94V0 Rating |
| Inslulation Resistance |
Min 10 Megohms @ 500 VDC |
| Dielectric Strength |
1500 VAC for one minute |
| Operating Temperature |
Ball Bearing :- 20 ~ + 80 *
Sleeve Bearing : - -10 ~ 56 * C. |
| Net Weight |
530 grms |
|
| |
|
|
|
|
|
|
| |
|
|
|
