| Products / General Technical Information |
| Rated Voltage VDC |
AC maximum Working Voltage (50 / 60Hz) |
Rated Voltage VDC |
AC maximum Working Voltage (50 / 60Hz) |
| 50V | 40V r.m.s | 800V | 250V r.m.s |
| 63V | 40V r.m.s | 1000V | 400V r.m.s |
| 100V | 63V r.m.s | 1200V | 450V r.m.s |
| 200V | 100V r.m.s | 1600V | 500V r.m.s |
| 250V | 160V r.m.s | 2000V | 600V r.m.s |
| 400V | 200V r.m.s | 2500V | 650V r.m.s |
| 630V | 220V r.m.s | 3000V | 700V r.m.s |
¤ The above AC voltage is not always common to all capacitor type.For details, consult our sale office or sales representative.
| Type of capacitor | Inherent temperature rise |
| Polyester Capacitors Metalized Polyester Capacitors |
Within 15°C |
| Polypropylene Capacitors | Within 10°C |
| Polypropylene Capacitors Metalized Polypropylene Capacitors |
Within 5 °C |
